ksd302 20A-70A 3/4'' disc bimetal thermostat 30-230C for water heater

Product Categories

esun electronic sci&tech.co.,ltd

Contact Now

ksd302 20A-70A 3/4'' disc bimetal thermostat 30-230C for water heater

Name: ksd302 20A70A 34 disc bimetal thermostat 30230C for water heater
Brand: Esun
Price: 1.9 USD

Place of Origin : china

Brand Name : Esun

Model Number : 17am,KSD301,ksd302.BW9700

Certification : UL,VDE,RoHS

Price : 1.9

Packaging Details : bags cartons

Delivery Time : 15days

Payment Terms : T/T;paypal

Supply Ability : 80000PCS/WEEK

MOQ : 500PCS

voltage : 250V

current : 20-70A

temperature : 40-160C

contact type : normal closed and normal opened

certification : UL VDE RoHS

Contact Now

Water heater thermostats instead of 59T 66T
This temperture control would be suit to Water Heater
UL and CUL TUV approval

C-200 series 3/4" water heater thermostats instead of TOD 59T 66T 89T

Universal replacements for electric water heater thermostat and limts

Surface Mount Temperture Sensing Controls

Features

High electrical capacity

Snap-Action contact

Long life-proven reliability

Adjustable control or manual reset styles

Description	Range	SwithAction	A.C.ElectricalRatings
			(Non-Inductive)
			120/240 VAC	227 VAC	480 VAC
Manualreset	60-220°F (71-104°C)	SPST	-	40.0A	25.0A
			30.0A	25.0A	12.5A
		DPST
			40.0A	25.0A	12.5A
Adjustable	90-170°F (32-66°C)	SPST	-	40.0A	25.0A
			30.0A	25.0A	12.5A
		SPDT
			40.0A	25.0A	12.5A

NOTE: If those shown are not acceptable, Please contact us to discuss specific requirement
ksd302 20A-70A 3/4'' disc bimetal thermostat 30-230C for water heater

ksd302 20A-70A 3/4'' disc bimetal thermostat 30-230C for water heater
